MFWSF100

Mounting Frame for Single-station In-wall Non-refrigerated SwirlFlo® Bottle Filling Stations

Product Support
Installation Location Indoor
Application Type Hospitality
Accessory Type Mounting Options
Power No Electrical Required
Material Galvanized Steel
Finish Galvanized Steel
Number of Stations 1
Mounting Option Wall Mount (Inwall Frame/Plate)
Included with Product Mounting Frame Assembly
Shipping Dimensions L: 39-1/4"
W: 19-1/8"
H: 8-1/2"
Shipping Weight 28 LBS
Note Mounting frame included with Elkay (L)EZWS-EDFPBM114K non-refrigerated models.

We carry a range of mounting frames, plates and other installation support systems to properly position and enhance our refrigerated and non-refrigerated bottle filling stations, water coolers, drinking fountains and chillers of all configurations.

  • Single-station mounting frame enables installation of in-wall drinking water models
  • Compatible with specific Elkay® non-refrigerated models; see specifications tab for details
  • Mounting frame included with specific SwirlFlo® models
  • Secures directly to a variety of load-bearing surfaces
  • Refer to end product for ADA compliance information
  • Built in the USA
