MFWSF110

Mounting Frame for Single-station In-wall Refrigerated SwirlFlo® Bottle Filling Stations

Product Support
Installation Location Indoor
Type Mounting Options
Power No Electrical Required
Material Galvanized Steel
Finish Galvanized Steel
Number of Stations 1
Mounting Type Wall Mount (In-Wall Frame/Plate)
Included with Product Mounting Frame Assembly
Country Of Origin USA
Dimensions L: 18-11/16"
W: 12"
H: 54-15/16"
Shipping Dimensions L: 59-3/4"
W: 19-1/8"
H: 8-1/2"
Shipping Weight 35 LBS
Note Mounting frame included with Elkay LZWS-LRPBM8K & EZWS-ERPBM8K refrigerated models.

We carry a range of mounting frames, plates and other installation support systems to properly position and enhance our refrigerated and non-refrigerated bottle filling stations, water coolers, drinking fountains and chillers of all configurations.

  • Single-station mounting frame enables installation of in-wall drinking water models
  • Compatible with specific Elkay® refrigerated models; see specifications tab for details
  • Mounting frame included with specific SwirlFlo® models
  • Secures directly to a variety of load-bearing surfaces
  • Refer to end product for ADA compliance information
  • Built in the USA
