EZWS8K

ezH2O® In-Wall Bottle Filling Station Non-Filtered Refrigerated Stainless

Product Support
ADA Yes
Installation Location Indoor
Power 115V/60Hz
Material Stainless Steel
Finish Stainless Steel
Features Antimicrobial
Green Ticker™
Hands Free
Laminar Flow
Real Drain
Number of Stations 1
Bubbler Style No Bubbler
Filtered No
Chilling Capacity 8.0 GPH
Mounting Type Wall Mount (In-Wall Frame/Plate)
Included with Product Bottle Filler (EZWSM8C)
Chiller (ECH8)
Ships In Multiple Boxes Yes
Country Of Origin USA
Dimensions L: 19-3/4"
W: 3-1/2"
H: 40-13/16"
Shipping Dimensions L: 28-1/4"
W: 39-3/4"
H: 22"
Shipping Weight 63 LBS
Note Requires mounting frame MFWS100 which is ordered seperately for early installation.
Code Compliance CSA C22.2 No. 120
UL 399
NSF 61
NSF 372

The Elkay EZH2O® Bottle Filling Station delivers a clean quick water bottle fill and enhances sustainability by minimizing our dependency on disposable plastic bottles. Fully recessed in-wall design. Sanitary no-touch sensor activation with automatic 20-second shut-off timer.

  • Designed as a stand-alone unit or to be paired with Elkay® SwirlFlo or Soft Sides® architectural fountains
  • Hermetically sealed refrigeration system provides chilled water to satisfy thirst
  • Touchless, sensor-activated bottle filler designed for easy use
  • Fill rate is 1.1 GPM
  • Green Ticker™ informs user of number of 20 oz. plastic water bottles saved from waste
  • Key plastic components are manufactured with silver ion antimicrobial agent helping to provide clean, stain- and odor-free surfaces
  • Silver ion antimicrobial protection on key plastic components to inhibit the growth of mold and mildew
  • Real drain system eliminates standing water
  • Rated for indoor use
